OEM Compatability
ENTEK manufactures twin-screw extruder replacement screws and barrels for other OEMs, including:
Coperion
Leistritz
Century
NFM
JSW
Berstorff
Steer
Toshiba
and Others!
Let ENTEK be your one stop shop for twin-screw extruder replacement screws.
Call 541.208.6251 if you have any questions.
Sizes – All
Surface Treatment – Through Hardened
Surface Hardness – 58 – 60 HRc
Specifications – Solid D2 Tool Steel
Applications – Low corrosion applications with more wear resistance than N135.
Through hardened so wear does not accelerate toward end of life.
Sizes – All
Surface Treatment – Through Hardened
Surface Hardness – 46 – 49 HRc
Specifications – Solid H13
Applications – Used in high impact zones, feed screws (CoFs), and mixing elements (CoMs). Through hardened so wear does not accelerate toward end of life.
Sizes – 27mm – 43mm
Surface Treatment – Through Hardened
Surface Hardness – 60 – 62 HRc
Specifications – PM10V Solid
Applications – High wear, non-corosive applications such as highly filled color compounding.
Sizes – 53mm and up
Surface Treatment – PM – HIP
Surface Hardness – 60 – 62 HRc
Specifications – PM10V bi-metallic (mild steel core)
Applications – High wear, non-corosive applications such as highly filled color compounding.
Sizes – 27mm – 43mm
Surface Treatment – Through Hardened
Surface Hardness – 56 – 59 HRc
Specifications – PM10V-12 Solid
Applications – High wear, high corrosion applications such as organic fiber, aggressive volatiles, solvents/acids, in conjunction with abrasive components.
Sizes – 53mm and up
Surface Treatment – PM – HIP
Surface Hardness – 56 – 59 HRc
Specifications – PM10V-12 bi-metallic (mild steel core)
Applications – High wear, high corrosion applications such as organic fiber, aggressive volatiles, solvents/acids, in conjunction with abrasive components.
Size – Used primarily for 27mm and 33mm non-sleeved feed barrels
Surface Treatment – Nitrided
Surface Hardness – 61 – 63 HRc
Specifications – Non-sleeved, N135
Applications – Low wear, low corrosion applications such as color compounding, or where high toughness is required; feed barrels on 43mm, 73mm, and 103mm.
Size – All
Surface Treatment – Nitrided
Surface Hardness – 52 – 58 HRc
Specifications – Sleeved, cast material
Applications – Medium wear, medium corrosion applications providing more wear and corrosion resistance than 10B.
Size – 27mm – 40mm
Surface Treatment – Through Hardened
Surface Hardness – 60 – 62 HRc
Specifications – Sleeved, PM10V solid
Applications – High wear, high corrosion applications such as abrasive mineral fill, silica, fiberglass, organic fiber and /or chemical solvents, acids.
Size – 27mm – 40mm
Surface Treatment – Through Hardened
Surface Hardness – 56 – 59 HRc
Specifications – Sleeved, PM10V-12 Solid
Applications – High wear, high corrosion applications such as abrasive mineral fill, silica, fiberglass, organic fiber and /or chemical solvents, acids.
Size – 43mm and up
Surface Treatment – PM – HIP
Surface Hardness – 60 – 62 HRc
Specifications – Sleeved, PM10V bi-metallic
Applications – High wear, high corrosion applications such as abrasive mineral fill, silica, fiberglass, organic fiber and /or chemical solvents, acids.
Size – 43mm and up
Surface Treatment – PM – HIP
Surface Hardness – 61 – 63 HRc
Specifications – Sleeved, proprietary blend with increased chromium content over 61H
Applications – High wear, high corrosion applications such as abrasive mineral fill, silica, fiberglass, organic fiber and /or chemical solvents, acids.
Twin-Screw Extruder Screw Layout Designer
Access ENTEK’s software program designed for customers to quickly and easily design twin-screw extruder screw and barrel layouts for specific applications.
Some of the built-in features of this software are:
- Metallurgy shown visually for barrels and screws, with key at bottom
- Incompatibilities trigger pop up warnings as they occur in the layout when best practices are not followed, and are listed on the printed or saved layout
- Ability to include materials and item numbers on printed or saved layout for ease of ordering replacement parts
- The file created can be exported to Excel where a spreadsheet list and a pictorial layout are printable
